Dynair Box-CA Active carbon filtering units

QUICK OVERVIEW

Construction

Frame in extruded aluminium profi les and removable double skin panels in galvanized steel sheet
Lining of the plenum with self-extinguishing techno-polymer material
Double inlet centrifugal fan with forward curved blades, driven by trapezoidal belts and adjustable pulleys. Fan and motor supported by single base frame and isolated from the main structure by anti-vibration mounts and flexible joint on the outlet
Filtering battery composed by wavy polyester pre-filter (class G3), pocket filter (class F7) and activated charcoal filter in cartridges
Asynchronous three-phase motors according to international standards IEC 600034, IEC 60072, EMC 2014/30/UE, LVD 2014/35/UE, CE marked, IP 55, class F. Suitable for S1 service (continuous working at constant load)

Accessories

Weatherproof cover

CATALOGUE

Description

The BOX-CA units are the ideal solution for air filtering and for smells removal. Ideal for commercial environments (bar, restaurants, etc). and industrial plants where noise and bad smells are a problem.

The quality of the air is granted by a series of filtering sections crossed by the airflow. The low noise level is granted by the thick acoustic insulation of the double skin panels.
Suitable for air temperature from -15°C of 50°C.
